Teco 990

Telecamere

The wheel aligner and pre-check for cars and light-duty vehicles with 4 Hi-Qi cameras.

Teco 990 is the new wheel aligner with passive targets and 4 high-resolution digital cameras, to ensure measurement maximum precision and accuracy. The automation of wheel alignment operations and the extreme reliability of components enhance its productivity.

Equipped with:

4 Hi-Q cameras. Operating light indicators
Column-integrated lift with target automatic tracking function
Ergonomic shelf with additional USB ports
Presetting for additional monitor or A4 printer
Presetting for trolley

Technology at your service: simple, quick, accurate.

The wheel aligner is compatible with the new universal system.

Technical data

Total toe	± 20°
Semi-toe	± 10°
Camber	± 10°
Caster	± 30°
Kingpin	± 30°
Thrust angle	± 10°
Steering difference at 20°	± 10°
Power supply voltage	115/230 Vac - 50/60 Hz - 1 Ph
Absorbed power	500 W
Central unit (cabinet)	35 kg
Camera head	40 kg
Column	125 kg

Supplied as standard, positioning precision reaches extreme levels. The lift allows the operator to work from the pit to a height of more than 2 metres by pressing a key on the keyboard. Fast and easy to use.

Its compact design makes it suitable to installations in small rooms and to installations with 4-column lifts.

Compatible with pits and scissor lifts, 4-column and parallelogram lift installations. For 4-column lifts, the minimum internal column distance required to operate on production vehicles is of 2900 mm.

The wheel aligner is compatible with the new PROADAS universal system used for the calibration of driver assistance systems on new-generation vehicles.
